DescriptionFit with an up-to-date power supply device, float charger BAC1210 is specially designed to meet the charging characteristics of the lead-acid engine starter batteries and can be used for long-term float charging of 12V lead-acid batteries.PERFORMANCE AND CHARACTERISTICS: Switch power supply structure, wide input alternating voltage range, small size, lightweight, high-efficiency rate; Automatic two-stage charging process (first constant current, then constant voltage) carried out according to storage battery charging characteristics to prevent overcharging and significantly prolong battery lifetime; Built-in current protective circuit, which can give effective protection when output over current, short-circuit, or reverse connection occurs. Regard power lamp or charge lamp fast blinking as an alarm. Suitable for 12V storage battery and the rated current is 10A; LED display: Power indication (Green light) and charging indication (Red light).TECHNICAL SPECIFICATIONS: Battery Voltage: 12V Max. Charging Current: 10A Rated Input Voltage: (100~240)V Max. Input Voltage Range: (90~280)V AC Input Frequency: (50/60)Hz Max. Input Current: 2.5A No-Load Power Consumption: 3W Operating Mode: Two segments Maximum Efficiency: 83% Operating Temp: (-30~ 55)℃ Storage Temp: (-40~ 85)℃ Net Weight(kg): 0.8 Case Dimensions(mm): 145.5*131*55
